Short Description
- Copper 24AWG (0.5mm)
- 24 AWG Drain Wire (0.4mm)
- Two Twisted Wires
- Packaging 500 or 1000 Meters
- Nylon Rip Cord
- No Cross Talk
- All Pairs Can Be Used Simultaneously
- Aluminium Foil Wrapped
- Mylar Protection
Shipping & Return
Cancellation Policy
- An order will instantly be canceled if the billing information is inaccurate or incomplete.
- If a customer doesn’t confirm his/her order within 48-hours of placement, the order will be marked as ‘discarded’.
- An order can only be canceled within 3 hours of placing the order.
Exchange Policy
- An item can only be exchanged in case of any defects with proof, within 2 days of delivery.
- An item will only be exchanged with an intact duplicate that doesn’t contain the same defects as the former.
- To exchange a purchased product, the customer will have to submit a request form with proof and details of the defected items and company will have full authority to decline the request depending upon the availability of the product.
Product Description
1. Conductor
-
Nos.: — (not specified)
-
Diameter: 0.5 mm
-
A.Q.L.: (+0.001 / -0.010)
-
Material: Solid Bare Copper
2. Insulation
-
A.Q.L.: (+/-0.10)
-
Material: General PVC Insulation
3. Shield (1)
-
Material: Spiral Mylar Transparent Shield
4. Drain Wire
-
Nos.: 1
-
Diameter: 0.4 mm
-
A.Q.L.: (+0.001 / -0.008)
-
Material: Tinned Copper
5. Shield (2)
-
Material: Spiral Aluminium Foil Shield
6. Sheath
-
Overall Diameter: 11.1 mm
-
A.Q.L.: (+/-0.20)
-
Material: Grey PVC Jacket with Rip-Cord
CHARACTERISTICS
Property
Test Condition
Specification
Conductor DC Resistance
20°C
< 7.31 Ω / 100 m
Insulation Resistance
20°C
> 200 MΩ·M
Rated Temperature
—
60°C
Rated Voltage
—
30 V
Nos.: — (not specified)
Diameter: 0.5 mm
A.Q.L.: (+0.001 / -0.010)
Material: Solid Bare Copper
A.Q.L.: (+/-0.10)
Material: General PVC Insulation
Material: Spiral Mylar Transparent Shield
Nos.: 1
Diameter: 0.4 mm
A.Q.L.: (+0.001 / -0.008)
Material: Tinned Copper
Material: Spiral Aluminium Foil Shield
Overall Diameter: 11.1 mm
A.Q.L.: (+/-0.20)
Material: Grey PVC Jacket with Rip-Cord
| Property | Test Condition | Specification |
|---|---|---|
| Conductor DC Resistance | 20°C | < 7.31 Ω / 100 m |
| Insulation Resistance | 20°C | > 200 MΩ·M |
| Rated Temperature | — | 60°C |
| Rated Voltage | — | 30 V |
