Short Description
- Balanced Mic Inputs (Ch.1–6)
- Line, Link, Amp & Remote Inputs
- Frequency Response 100 Hz–10 kHz
- Output Power 120W @ THD 0.5%
- Graphic EQ 7-Band (±12 dB)
- Phantom Power 15 VDC
- Dimensions 420×88×320 mm
- Net Weight 9.76 kg
Shipping & Return
Cancellation Policy
- An order will instantly be canceled if the billing information is inaccurate or incomplete.
- If a customer doesn’t confirm his/her order within 48-hours of placement, the order will be marked as ‘discarded’.
- An order can only be canceled within 3 hours of placing the order.
Exchange Policy
- An item can only be exchanged in case of any defects with proof, within 2 days of delivery.
- An item will only be exchanged with an intact duplicate that doesn’t contain the same defects as the former.
- To exchange a purchased product, the customer will have to submit a request form with proof and details of the defected items and company will have full authority to decline the request depending upon the availability of the product.
Product Description
-
Inputs: Mic (Ch.1–5 -50 dB), Line (-6 dB), Mic Ch.6 (-50 ~ -6 dB), Tele-Paging/MIC (-40 ~ 0 dB), Link-In (-17 dB), Amp-In (0 dB), Remote Paging (+18 dB), RCA (-30 ~ +14 dB)
-
Audio: Freq. Response 100 Hz–10 kHz (+1.5/-3 dB), EQ 125 Hz–8 kHz (±12 dB), S/N >75 dB, Crosstalk -60 dB @1 kHz, THD <0.5% @1 kHz, Phantom Power 15 VDC
-
Output/Load: 120W @0.5% THD, 8Ω (31 V), 70 V (40.8Ω), 100 V (83Ω)
-
Mechanical: Cooling Convection, Size 420×88×320 mm, Weight 9.76 kg, Temp 0–40°C
Inputs: Mic (Ch.1–5 -50 dB), Line (-6 dB), Mic Ch.6 (-50 ~ -6 dB), Tele-Paging/MIC (-40 ~ 0 dB), Link-In (-17 dB), Amp-In (0 dB), Remote Paging (+18 dB), RCA (-30 ~ +14 dB)
Audio: Freq. Response 100 Hz–10 kHz (+1.5/-3 dB), EQ 125 Hz–8 kHz (±12 dB), S/N >75 dB, Crosstalk -60 dB @1 kHz, THD <0.5% @1 kHz, Phantom Power 15 VDC
Output/Load: 120W @0.5% THD, 8Ω (31 V), 70 V (40.8Ω), 100 V (83Ω)
Mechanical: Cooling Convection, Size 420×88×320 mm, Weight 9.76 kg, Temp 0–40°C
