Belden Security & Sound, 3 Conductor 16 AWG, BC, CM 5201UE
₨ 683
Per meter
Short Description
- 3×16 AWG stranded copper for intercom and sound systems
- Polypropylene insulation with Beldfoil® shield for full noise protection
- PVC riser-rated jacket with ripcord for easy installation
- Low resistance (4 Ω/1000 ft) ensures clear, stable signal
- Rated 300V / 75°C, UL1666, FT4, CE, RoHS II, CMR compliant
Shipping & Return
Cancellation Policy
- An order will instantly be canceled if the billing information is inaccurate or incomplete.
- If a customer doesn’t confirm his/her order within 48-hours of placement, the order will be marked as ‘discarded’.
- An order can only be canceled within 3 hours of placing the order.
Exchange Policy
- An item can only be exchanged in case of any defects with proof, within 2 days of delivery.
- An item will only be exchanged with an intact duplicate that doesn’t contain the same defects as the former.
- To exchange a purchased product, the customer will have to submit a request form with proof and details of the defected items and company will have full authority to decline the request depending upon the availability of the product.
Product Description
-
Versatile Signal & Control Cable: This 3-conductor, 16 AWG stranded bare copper cable is ideal for addressable fire systems, data circuits, monitoring, control, and notification applications, ensuring consistent signal integrity in commercial and security systems.
-
Robust Electrical Performance: Offers low conductor resistance (4.2 Ω/1000 ft), capacitance of 23.5 pF/ft, and supports up to 6.25 A per conductor at 25°C, enabling stable and efficient current flow.
-
High-Quality Construction: Each conductor is insulated with polyolefin (0.008 in thick), color-coded black, red, and white for simplified identification and wiring accuracy.
-
Durable Outer Jacket: The PVC jacket (0.017 in thickness, 0.191 in overall diameter) with a ripcord ensures easy stripping, excellent flexibility, and protection from mechanical stress during installation.
-
Certified and Compliant: Rated for 300V (CMR) and 75°C, meeting UL1666 (Riser), FT4, IEC 60332-1-2, NEC Article 800, and CE, UKCA, RoHS II, WEEE, and China RoHS II environmental directives for safe, long-lasting indoor riser applications.
Versatile Signal & Control Cable: This 3-conductor, 16 AWG stranded bare copper cable is ideal for addressable fire systems, data circuits, monitoring, control, and notification applications, ensuring consistent signal integrity in commercial and security systems.
Robust Electrical Performance: Offers low conductor resistance (4.2 Ω/1000 ft), capacitance of 23.5 pF/ft, and supports up to 6.25 A per conductor at 25°C, enabling stable and efficient current flow.
High-Quality Construction: Each conductor is insulated with polyolefin (0.008 in thick), color-coded black, red, and white for simplified identification and wiring accuracy.
Durable Outer Jacket: The PVC jacket (0.017 in thickness, 0.191 in overall diameter) with a ripcord ensures easy stripping, excellent flexibility, and protection from mechanical stress during installation.
Certified and Compliant: Rated for 300V (CMR) and 75°C, meeting UL1666 (Riser), FT4, IEC 60332-1-2, NEC Article 800, and CE, UKCA, RoHS II, WEEE, and China RoHS II environmental directives for safe, long-lasting indoor riser applications.
